Chemicalsandelectricdiagrams
Electricsymbols



Transformer: "Two coils of wire linked by an iron core. Transformers are used to step up (increase) and step down (decrease) AC voltages. Energy is transferred between the coils by the magnetic field in the core. There is no electrical connection between the coils."

(http://www.kpsec.freeuk.com/symbol.htm)

Earth



Earth (Ground): "A connection to earth. For many electronic circuits this is the 0V (zero volts) of the power supply, but for mains electricity and some radio circuits it really means the earth. It is also known as ground."

Preset




Variable Resistor (Preset): This type of variable resistor (a preset) is operated with a small screwdriver or similar tool. It is designed to be set when the circuit is made and then left without further adjustment. Presets are cheaper than normal variable resistory so they are often used in projects to reduce the cost.
